DBW125
As low as
$195.00
In stock
Only %1 left
SKU
DBW125
- Laser Safety Windows are priced in single square foot increments
- Available stock at 24" x 36" x .145" and special order up to 36" x 48" x .145"
- Allow + or - 1/8" tolerance in width and length
- Custom cuts available
- For Nd:YAG (1064nm) and its harmonics: 532nm (second), 355nm (third), 266nm (fourth), 213nm (fifth).
Coverage also protects laser hazards at 455nm, 488nm, 514nm (Argon), 511nm (Copper Vapor),
532nm (Doubled YAG for KTP therapy), 190nm to 532nm (Excimer, UV Curing, Blue light curing), and 10,600nm (CO2).
available stock at 24" x 36" x .145" and special order up to 36" x 48" x .145"
Nd:YAG + Harmonics- For Nd:YAG (1064 nm) and its harmonics: 532 nm (second), 355 nm (third), 266 nm (fourth), 213 nm (fifth). Coverage also protects against laser hazards at 455 nm, 488 nm, 514 nm (Argon), 511 nm (Copper Vapor), 532 nm (Doubled YAG for KTP therapy), 190 nm to 532 nm (Excimer, UV Curing, Blue light curing), and 10,600 nm (CO2)
- Priced in single square foot increments.
| Final product CE certified: | Yes |
|---|---|
| Product Category Type: | Laser Filter |
| Lens Color: | Amber |
| VLT: | 17% |
| EN 12254 Rating: | D AB7 + IR AB3 190–315 DIR AB5 + M AB5Y >315–533 DIR AB4 + M AB4Y 850 –880 D AB4 + IR AB6 + M AB6Y >880–1100 DI AB2 10600 |
| Ce Certified: | Yes |
| Wavelength (nm) / OD: | 190-533 OD 5+ 850-879 OD 4+ 880-1100 OD 5+ 1064 OD 6+ 10600 OD 5+ |
| Disclaimer: | Filter characteristic data points are nominally represented here solely for informational purposes. We guarantee only those specifications, including Optical Densities, CE ratings and VLT, that are imprinted on the eye protectors and listed on filter data sheets and web pages. |
| Filter Material: | Acrylic |
| 1+1: | No |
| Is New Frame: | No |
